With a high impact power and giving 2,400 blows/min., our BRK 25 D D-handle hammer is the powerful choice for horizontal work in renovation, demolition and structural alteration. The detachable front handle, available as an optional extra, pivots 360° for optimal positioning. The tool is well balanced, with no external side bolts and protruding machine parts that can come into contact with the operator’s body.
Common Characteristics
Easy handling
Lightweight for horizontal work
Easy operation
Slim design for excellent line of sight to the working tool point
Fast preparation
Fitted with flat face quick-release couplings for fast, easy connections
Technical Data
| Parameter | Value |
|---|
| Weight Without Hoses | 12.6
kg |
| Length | 650
mm |
| Oil Flow | 20
l/min |
| Working Pressure | 80-100
bar |
| Maximum Return Line Pressure | 10
bar |
| EHTMA Class | C
|
| Vibration Level 3 Axes (ISO 28927-10) | 16.5
m/s2 |
| Sound Power Level Guaranteed (2000/14/EC) | 105
dB(A |
| Sound Pressure Level (ISO 11203) (Lp, r=1m) | 92
dB(A |
| Impact Rate | 2.300
blow/min |
| Shank Size Hex | 22 x 82.5
mm |
| Part Number | 1801 1746 12
|
