Handling & General Application Industrial Robots Yaskawa Motoman GP-series

MOTOMAN GP is a series of industrial robots offering a wide variety of work ranges and load capacity. They are compact and fast in their work, easy to install and operate.
Common Characteristics

GP robots work with the new YASKAWA YRC1000 and YRC1000 Micro controllers. The load capacity is between 7 and 600 kg. and working range from 707 to 4004mm. They have applications in all industries including food and medical industry. They are used both for picking parts and for machining parts with different tools. They are ideally integrated into various automated systems and successfully work with other machines and equipment.

Parameter GP7 GP8 GP12 GP25 GP35L
Controlled axes 6 pcs 6 pcs 6 pcs 6 pcs 6 pcs
Max. payload 7 kg 8 kg 12 kg 25 kg 35 kg
Max. working range 927 mm 727 mm 1440 mm 1730 mm 2538 mm
Repeatability ±0.03 mm ±0.02 mm ±0.06 mm ±0.06 mm ±0.07 mm
Weight   34 kg   32 kg 150 kg 250 kg  600 kg

Parameter GP50 GP88 GP110 GP180 GP215
Controlled axes 6 pcs 6 pcs 6 pcs 6 pcs 6 pcs
Max. payload 50 kg 88 kg 110 kg 180 kg 215 kg
Max. working range 2061 mm 2061 mm 2236 mm 2702 mm 2912 mm
Repeatability ±0.07 mm ±0.07 mm ±0.07 mm ±0.05 mm ±0.2 mm
Weight 570 kg 630 kg 660 kg 1020 kg 1340 kg

Parameter GP225 GP250 GP280 GP400 GP600
Controlled axes 6 pcs 6 pcs 6 pcs 6 pcs 6 pcs
Max. payload 225 kg 250 kg 280 kg 400 kg 600 kg
Max. working range 2702 mm 2710 mm 2061 mm 2446 mm 2942 mm
Repeatability ±0.05 mm ±0.2 mm ±0.05 mm ±0.05 mm ±0.1 mm
Weight 1080 kg 1345 kg 1300 kg 2840 kg 3035 kg



MOTOMAN YRC1000 industrial robot controller

The MOTOMAN YRC1000 is a compact, fast and flexible controller for MOTOMAN robots that combines high performance robot control in a small footprint cabinet with volume of 125 litres and a maximum weight of 70 kg. Besides the typical YASKAWA controller functionality, the YRC1000 includes additional functional improvements. Speed of the controller has been increased by lowering a ladder scanning time.



Specifications

Dimensions 598 (W) x 490 (H) x 427 (D) mm
Approx. weight 70 kg
Cooling system Indirect cooling
Ambient temperature During operation: 0°C to +45°C
During storage: -10°C to +60°C
Relative humidity 90 % Max.
Power supply 380-440 VAC (+10 %, -15 %), 50/60 Hz (±2 %)
Protection class IP 54
Digital I/O's Specialized signals: 19 inputs and 6 outputs
General signals: 40 inputs and 40 outputs
Programming capacity JOB: 200,000 steps, 10,000 instructions
